| FM BROADCAST TRANSMITTER 88-108 MHz 30 W |
| |
|
 |
 |
| |
| FREQUENCY RANGE |
87.5 ÷ 108 MHz |
| MODULATION |
FM |
| EMISSION CLASS |
F3E |
| VCO TUNING |
25 MHz |
| FREQUENCY STABILITY |
± 2.5 ppm |
| SYNTHESIZER STEP |
100KHz opz. 10KHz |
| POWER OUTPUT |
30 watt |
| SPURIOUS EMISSION |
< - 80 dB or better |
| HARMONIC EMISSION |
< - 70 dB |
| STEREO SEPARATION |
> 55 dB @ 1KHz (typ. 60dB) |
| DISTORSION |
< 0.1 % (typ. 0.06%) @ 1KHz |
| BASE BAND |
30 Hz ÷ 60 KHz within 0.15 dB |
| UNWEIGHTED S/N RATIO |
>80 dB (30Hz ÷ 15KHz 50 µS RMS) |
| ASYNCRONOUS AM S/N Ratio |
> 70 dB Ref. 100% AM 400Hz |
| SYNCRONOUS AM S/N Ratio |
> 65 dB with FM @ 75KHz @400Hz |
| PRE-EMPHASIS |
50 OR 75 µS int. selectable |
| RF OUT CONNECTOR |
DIN 7/16 - 50 Ohm |
| MPX INPUT CONNECTOR |
BNC - Female |
| MPX INPUT IMPEDANCE |
2 KOhm |
| COOLING |
Convection for RF PA and a fan for PS |
| OP.TEMPERATURE RANGE |
0 ÷ +45 °C |
| MAXIMUM HUMIDITY |
90 % |
| AC SUPPLY |
100 ÷ 240 VAC - 47 ÷ 63 Hz |
| DIMENSION |
320 mm front, 254 mm depth |
| WEIGHT |
4 Kg |
|
 |
| |
| EMISORA FM BROADCAST 88-108 MHz 30 W. |
| |
Esta emisora permite transmitir con alta calidad sin ningún equipo externo, pudiendo grabar varios días de programación en memoria flash. Con este sistema la calidad de la Emisión es muy alta sin inversión alguna. Ideal para emisoras locales o de organizaciones. También tiene entrada analógica estéreo para usarla con ordenador o mezclador. |
| FM BROADCAST TRANSMITTER 88-108 MHz 30 W. |
| |
This station allows to transmit with high quality without any external equipment, being able to record several days of programming in flash memory. With this system the quality of broadcast is very high without any investment. Ideal for local stations or organizations. It also has stereo analog input for use with computer or mixer. |
| |
